Aguilar Filtertwin v2 Twin Envelope Filter Pedal

Aguilar Filtertwin v2 Twin Envelope Filter Pedal

New look for 2023, same great filter pedal!

The Filter Twin uses two identical filters sweeping in opposite directions one up in frequency, one down in frequency to give classic 70s-inspired funk sounds and completely new and original filter tones. With both filters sweeping at the same time you can achieve more organic, vocal qualities not found in other filter pedals.

The Filter Twin offers unique filter effects via an intuitive four-knob layout. The BLEND control allows you to adjust the mix between the filters. The THRESHOLD control determines how sensitive the unit is to different playing styles. The VELOCITY controls determine the speed of each filter.

FEATURES

• Separate velocity controls for the up and down filters
• Blend control adjusts mix between the filters
• Inputs: One 1/4 jack
• Outputs: One 1/4 jack
• Power: 9v power supply
• Warranty: Three year limited

FUNCTIONS

• BLEND: Pans between the up and down filters. The up filter control is indicated by an arrow pointed up. The down filter control is indicated by a down arrow.
• THRESHOLD: Controls the sensitivity of the unit to different input levels
• VELOCITY UP: Controls the speed of the up filter*
• VELOCITY DOWN: Controls the speed of the down filter*
• ENGAGE: Toggles between engage and bypass. The blue LED indicates that the effect is engaged.

*The filter velocity also depends on threshold settings and input level. As the threshold islowered and your bass input level is increased, the filter velocity increases as well sotweak away and have fun!

SPECIFICATIONS

• Current consumption: 10mA
• Input impedance: 1M (Effect On)
• Output impedance: 1 K
• Maximum Output: +6dBu (1.6VRMS)
• Noise Level: -94 dBu A weighted *
• Battery Power: 9V
• External DC Power: 9-10 VDC center terminal negative

* = All knobs set to 12 o’clock
